Commercial Crew Pumper
|
Type Pumper |
Build Number 12345 |
Chassis Model Kenworth T480 |
Engine Information 450 HP |
|
Gallonage 4000 |
Pump System Hale, MBP 1000 GPM |
Features
- Kenworth T480 chassis
- PACCAR PX-9 450 HP engine
- Allison 3000 EVS transmission
- Hale 1000 GPM PTO pump
- 4000 gallon poly tank
- 4000 gallon folding tank
- One (1) 10" Newton swivel dump valve
- Full-length hose bed
- Two (2) 2-1/2" direct tank fills
- AMDOR roll-up doors
- Whelen LED NFPA lighting & siren package
Features may vary based on your location and customization needs.
Chassis: Kenworth T480, 2-Door
Engine: Paccar PX-9, 450 HP
Transmission: Allison 3000, 5-Speed
GVW: 40,600 lbs. (Front Axle: 14,600 lbs | Rear Axle: 26,000 lbs.)
Wheels: Alcoa Mirror Polish Aluminum
Battery Conditioner: Kussmaul Chief 6012 series battery conditioner
Auxiliary Air Compressor: Kussmaul 12V auxiliary air compressor
Fuel Tank Capacity: 50 gallons
Air Horns: Two (2) Hadley chrome plated
Center Console: Yes
Tank: 4000 US gallons
Hard Suction: Two (2) 6.00″ X 10′ sections of suction hoses
Body: Aluminum diamond plate
Compartment Door Type: AMDOR roll-up doors, satin finish
Compartment L1 & R1: Approx. 60.00″W x 26.00″D x 27.00″H
Compartment L2 & R2: Approx. 60.00″W x 26.00″D x 27.00″H
Rear Camera Notch: Recessed mounting area for a backup camera
Rear Dump Value: Swivel and manual extension, Stainless Steel
Direct Tank Fill: Two (2) 2.50″ Akron
Hose Bed Cover: Vinyl
Additional: Custom in-house graphics can be applied to the unit
- Pump: Hale, MBP, 1000 GPM, Side Mount
- Special Features: Pump and Roll
- Pump Shift: Pump and Roll – MBP/RSD
- Hose Threads: NST hose threads
- Master Pump Drain: Class 1 master pump drain
- Priming System: Trident model manual AirPrime
- Intake Relief Valve: Class 1 stainless-steel intake relief valve
- Pressure Governor System: Fire Research Pump Boss Max series PBA501-D00
- Water Level Gauge: One (1) Innovative Controls Soft-Glo & Three (3) Innovative Controls Soft-Glo Mini Monster
- Discharges: Four (4) 2.50″, two (2) 1.75″
- 12 Volt Electrical System: Yes
- Cab Ground Lights: Two (2) LED chassis ground lights
- Ground Lights: Pump panel, front, and rear
- Ground Lights Activation: Activate when the parking brake is applied
- Emergency Lights: Whelen M Series Emergency Lights
- Scene Lights: Whelen EZ Series Scene Lights
- Lightbar: One (1) Whelen model JE2NFPA 56.00″ lightbar
- Siren and Control: One (1) Whelen model 295SLSA1
- Siren Speaker: One (1) Federal Signal model ES100
- Larger pumps – up to 1500 GPM
- Multiple dump valve configurations
- Side or top mount pump modules
- Deck gun
- Federal Q2B siren
- Hannay electric rewind booster reel
- SCBA bottle holders
